Pumps · Hazardous-area series
MG magnetic-drive sealless pump
Zero-leak pumping for toxic, flammable and high-value fluids. No mechanical seal to maintain.
Chemical processingPharmaceutical
- Flow range
- 5 – 1,200 gpm
- Max. head
- up to 500 ft
- Wetted materials
- 316 SS, Alloy C, ETFE-lined
- Temperature range
- -80 to 570 °F
Stocked at distributors·Typical lead time 7–10 days
Silicon-carbide bearings and a rare-earth coupling rated for full motor torque. Optional power-monitoring protects against dry run and decoupling.
Specifications
| Flow range | 5 – 1,200 gpm |
|---|---|
| Max. head | up to 500 ft |
| Wetted materials | 316 SS, Alloy C, ETFE-lined |
| Temperature range | -80 to 570 °F |
Need it sized?
Send fluid, flow and head. An application engineer returns a selection and curve within one business day.
